FANUC Series 30i-MODEL A
Tool center point control
for 5-axis machining
Ed. Date Design Description
Date Jan.16.’04 Design. Apprv.
- Angle of the rotary axis for type 2 (when the movement range is not specified)
When the direction of the tool is specified by I, J, K, Q for type 2, more than
two pairs of "computed angles" of the rotary axes usually exist.
The "computed angle" is the candidate angle at which the rotary axis is to be
controlled in the specified tool axis direction.
The "output angle" is determined from the "computed angle" based on the
"output judgment conditions" described below.
The following descriptions assume that there is no movement range
specification (parameter No.19741 - No.19744 = 0).
"Output judgment conditions"
Tool rotation type or table rotation type machine
<1> The "output angles" are represented by the computed rotary axis
angle pair whose master axis (first rotary axis) moving angle is
smaller.
↓
↓ When the master axis moving angle is the same
↓
<2> The "output angles" are represented by the computed rotary axis
angle pair whose slave axis (second rotary axis) moving angle is
smaller.
↓
↓ When the slave axis moving angle is the same
↓
<3> The "output angles" are represented by the computed rotary axis
angle pair whose master axis (first rotary axis) angle is nearer to 0
degree (multiple of 360 degrees).
↓
↓ When the master axis angle is equally near to 0 degree
↓
<4> The "output angles" are represented by the computed rotary axis
angle pair whose slave axis (second rotary axis) angle is nearer to 0
degree (multiple of 360 degrees).
Mixed type machine
<1> The "output angles" are represented by the computed rotary axis
angle pair whose table (second rotary axis) moving angle is smaller.
↓
↓ When the table moving angle is the same
↓
<2> The "output angles" are represented by the computed rotary axis
angle pair whose tool (first rotary axis) moving angle is smaller.
↓
↓ When the tool moving angle is the same
↓
<3> The "output angles" are represented by the computed rotary axis
angle pair whose table (second rotary axis) angle is nearer to 0
degree (multiple of 360 degrees).
↓
↓ When the table axis angle is equally near to 0 degree
↓
<4> The "output angles" are represented by the computed rotary axis
angle pair whose tool (first rotary axis) angle is nearer to 0 degree
(multiple of 360 degrees).
