FANUC Series 30i-MODEL A
Tool center point control
for 5-axis machining
Ed. Date Design Description
Date Jan.16.’04 Design. Apprv.
Parameters
#7 #6 #5 #4 #3 #2 #1 #0
1403 HTG
[Input type] Parameter input
[Data type] Bit path
# 5 HTG The feedrate of helical interpolation, helical involute interpolation, or
three-dimensional circular interpolation is:
0: Specified as the feedrate tangent to the arc, involute curve, or
three-dimensional arc.
1: Specified as the tangent feedrate including a linear axis (for
three-dimensional circular interpolation, a specified axis other than the
circular interpolation axis).
#7 #6 #5 #4 #3 #2 #1 #0
19608 HEL MIR PRI DET
[Input type] Parameter input
[Data type] Bit path
# 2 DET In tool center point control for 5-axis machining or cutter compensation for
5-axis machining, when the programming coordinate system is fixed on the
table, the relative and absolute positions of a programmed path are
displayed:
0: In the programming coordinate system (fixed on the table).
1: In the workpiece coordinate system (not fixed on the table).
# 5 PRI In tool center point control for 5-axis machining (type 2) or cutter
compensation for 5-axis machining (type 2), when more than one end point
candidate are present at the time of a rotation axis movement made by a
command such as I,J,K:
0: For tool rotation type and table rotation type machines, a combination
with which the master (first rotation axis) moves a small angle is
selected; for mixed-type machines, a combination with which the table
(the second rotation axis) moves a small angle is selected.
1: For tool rotation type and table rotation type machines, a combination
with which the slave (the second rotation axis) moves a small angle is
selected; for mixed-type machines, a combination with which the tool
(the first rotation axis) moves a small angle is selected.
# 6 MIR In tool center point control for 5-axis machining (type 2), when
programmable mirror image is turned on for a linear axis:
0: Mirror image is not applied to specified I,J,K.
1: Mirror image is applied to specified I,J,K.
