  2. Series 30i-MODEL A, Tool center point control for 5-axis machining

Series 30i-MODEL A, Tool center point control for 5-axis machining Additional Manual Page 58

Additional Manual
A-79348E
Title
Draw
No.
56/88
page
FANUC Series 30i-MODEL A
Tool center point control
for 5-axis machining
Ed. Date Design Description
Date Jan.16.’04 Design. Apprv.
• Figure copy (G72.1/G72.2)
• Absolute programming (G90)
• Incremental programming (G91)
• Tool offset increase (G45)
• Tool offset decrease (G46)
• Tool offset double increase (G47)
• Tool offset double decrease (G48)
- Modal G codes which can be valid when tool center point control is specified
The modal G codes listed bellow can be valid when tool center point control
is specified.
If other modal G codes are valid when tool center point control is specified,
alarm PS5421 occurs.
• Modal G codes which are included in "G codes which can be specified"
described above.
• Polar coordinate interpolation cancel mode (G13.1)
• Polar coordinates command cancel (G15)
• Input in inch (G20(G70))
• Input in mm (G21(G71))
• Polygon turning cancel (G50.2)
• Workpiece coordinate system selection (G54 - G59)
• Canned cycle cancel (G80)
• Constant surface speed control cancel (G97)
• Canned cycle : return to initial level (G98)
• Canned cycle : return to R point level (G99)
• Coordinate system rotation cancel or 3-dimensional coordinate
conversion mode off (G69)
• Feed per minute (G94)
• Polar coordinate interpolation mode cancel (G113)
• Mirror image off for double turret or balance cutting mode cancel (G69)
• Coordinate system rotation cancel or 3-dimensional coordinate
conversion mode off (G69.1)
• Feed per minute (G98(G94))
