57/88
page
FANUC Series 30i-MODEL A
Tool center point control
for 5-axis machining
Ed. Date Design Description
Date Jan.16.’04 Design. Apprv.
- Command for any axis not related to tool center point control
Command for any axis not related to tool center point control can not be
specified.
If such a command is specified, alarm PS5421 occurs.
- Linear axes for tool center point control
The basic three axes specified in the parameter No.1022 are the linear axes
for tool center point control.
Any axis parallel to the basic three axes can not be the linear axes for tool
center point control.
If the basic three axes are not specified in the parameter No.1022, alarm
PS5459 occurs.
Note
NOTE
・ This function is an option.
Previous page
Next page
