FANUC Series 30i-MODEL A
Tool center point control
for 5-axis machining
Ed. Date Design Description
Date Jan.16.’04 Design. Apprv.
No. Message Description
PS5459 MACHINE PARAMETER
INCORRECT
- A machine configuration parameter (parameter No.
19665 to No.19667 or 19680 to 19714 or No.12321) is
illegal.
- The axis which is specified in parameter No.19681 or
No.19686 is not a rotation axis.
- The basic three axes are not specified in the parameter
No.1022.
- In tool center point control (type 2) or cutter
compensation for 5-axis machining (type 2) or tilted
working plane command, the end point of rotation axis
can not exist within the region specified by parameters
No.19741 to No.19744.
- In tool center point control (type 2) or cutter
compensation for 5-axis machining (type 2), the end
point of rotation axis can not exist. Check the machine
configuration and the program.
- Tool center point control (type 2) or cutter compensation
for 5-axis machining (type 2) is specified when
hypothetical axis is used.
- Tool center point control (type 2) or cutter compensation
for 5-axis machining (type 2) is specified when the
programming coordinate system is the workpiece
coordinate system.
