FANUC Series 30i-MODEL A
Tool center point control
for 5-axis machining
Ed. Date Design Description
Date Jan.16.’04 Design. Apprv.
Alarm and message
No. Message Description
PS5420 ILLEGAL PARAMETER IN
G43.4/G43.5
A parameter related to tool center point control is illegal.
- Acceleration/deceleration before interpolation is invalid.
Set the parameter No.1660.
- Acceleration/deceleration before interpolation for rapid
traverse is invalid. Set bit 1 of parameter No. 1401, bit 5
of parameter No. 19501, parameter No.1671 and
No.1672.
PS5421 ILLEGAL COMMAND IN G43.4/G43.5 An illegal command was specified in tool center point
control.
- A rotation axis command was specified in tool center
point control (type 2) mode.
- With a table rotary type or mixed-type machine, a I,J,K
command was specified in the tool center point control
(type 2) command (G43.5) block.
- A command that does not move the tool center point
(only a rotation axis is moved) was specified for the
workpiece in the G02 mode.
- When the workpiece coordinate system is set as the
programming coordinate system (bit 5 (WKP) of
parameter No. 19696 is 1), G02 or G03 was specified
while the rotation axis was not perpendicular to the
plane.
- A G code which can not be used in the tool center point
control mode was specified.
- A modal G code which can not be used in the tool center
point control mode was valid.
- Command for an axis not related to tool center point
control was specified.
PS5422 EXCESS VELOCITY IN G43.4/G43.5 An attempt was made to make a movement at an axis
feedrate exceeding the maximum cutting feedrate by tool
center point control.
PS5425 ILLEGAL OFFSET VALUE The offset number is illegal.
