Additional Manual
A-79348E
Title
Draw
No.
68/88
page
FANUC Series 30i-MODEL A
Tool center point control
for 5-axis machining
Ed. Date Design Description
Date Jan.16.’04 Design. Apprv.
Parameter
No.
Setting
example
Description
19665#4 0 Automatic calculation for controlled-point shifting
19665#5 0 Controlled-point shift
19666 2.0 Tool holder offset value
19667
X0.0
Y0.0
Z0.0
Controlled-point shift vector
19680 21 Mechanical unit type
19681 5(B) Controlled axis number for the first rotation axis
19682 2(Y) Axis direction of the first rotation axis
19684 0 Rotation direction of the first rotation axis
19685 0.0
Rotation angle when the first rotation axis is a
hypothetical axis
19686 4(A) Controlled axis number for the second rotation axis
19687 1(X) Axis direction of the second rotation axis
19689 1 Rotation direction of the second rotation axis
19690 0.0
Rotation angle when the second rotation axis is a
hypothetical axis
19696#0 0 The first rotation axis is an ordinary rotation axis.
19696#1 0 The second rotation axis is an ordinary rotation axis.
19697 3 Direction of the reference tool axis
19698 0.0 Reference angle RA
19699 0.0 Reference angle RB
19700 5.0 Rotary table position (X-axis)
19701 2.0 Rotary table position (Y-axis)
19702 -15.0 Rotary table position (Z-axis)
19703 0.0
Intersection offset vector between the first and second
rotation axes of the table (X-axis)
19704 0.0
Intersection offset vector between the first and second
rotation axes of the table (Y-axis)
19705 0.0
Intersection offset vector between the first and second
rotation axes of the table (Z-axis)
19709 3.0
Intersection offset vector between the tool axis and the
first rotation axis of the tool (X-axis)
19710 0.0
Intersection offset vector between the tool axis and the
first rotation axis of the tool (Y-axis)
19711 2.0
Intersection offset vector between the tool axis and the
first rotation axis of the tool (Z-axis)
19712 0.0
Intersection offset vector between the second and first
rotation axes of the tool (X-axis)
19713 0.0
Intersection offset vector between the second and first
rotation axes of the tool (Y-axis)
19714 0.0
Intersection offset vector between the second and first
rotation axes of the tool (Z-axis)
