FANUC Series 30i-MODEL A
Tool center point control
for 5-axis machining
Ed. Date Design Description
Date Jan.16.’04 Design. Apprv.
19680 Mechanical unit type
[Input type] Parameter input
[Data type] Byte path
[Valid data range] 0 to 21
Specify the type of the mechanical unit.
PRM19680
Mechanical unit
type
Controlled rotation
axis
Master and slave
0
Mechanism having no
rotation axis
2
Tool rotation
type
Two rotation axes of
the tool
The first rotation axis is the master,
and the second rotation axis is the
slave.
12
Table rotation
type
Two rotation axes of
the table
The first rotation axis is the master,
and the second rotation axis is the
slave.
21 Mixed type
One rotation axis of the
tool + one rotation axis
of the table
The first rotation axis is the tool
rotation axis, and the second
rotation axis is the table rotation
axis.
First rotar
y
axis
(
master
)
Second rotar
y
axis
(
slave
)
First rotary axis (master)
Second rotary axis (slave)
Tool rotary
axes
Table rotary
axes
NOTE
A hypothetical axis is also counted as a controlled
rotary axis.
<Hypothetical axis>
In some cases, it is convenient to use an imaginary
rotary axis whose angle is fixed to a certain value.
For example, suppose that a tool is mounted in a
tilted manner through an attachment. In such a
case, the rotary axis considered hypothetically is a
hypothetical axis. Bits 0 and 1 of parameter No.
19696 determine whether each rotary axis is an
ordinary roatry axis or a hypothetical axis.
Previous page
Next page
