Servo Motor Alpha Series Maintenance manual Page 111

Maintenance manual
4. CONFIRMATION OF
B-65165E/02 START-UP PROCEDURE THE OPERATION
- 81 -
(2) SPMC
Data
No.
Description
Data
length
Remarks
Main data
19 Motor speed command 32 The 12th bit (bit 12) indicates the unit of
min
-1
.
8 Motor speed 32 The 12th bit (bit 12) indicates the unit of
min
-1
(only when a position coder is used)
13 Estimated motor speed 32 The 12th bit (bit 12) indicates the unit of
min
-1
.
18 Spindle speed 32 The 12th bit (bit 12) indicates the unit of
min
-1
(only when a position coder is used)
7 Motor speed deviation 32 (Speed command - motor speed). The
12th bit (bit 12) indicates the unit of min
-1
.
4 Move command 32 Number of command pulses for ITP
(usually 8 ms)
9 Position error 32 Number of erroneous pulses (spindle
synchronization, Cs contour control, rigid
mode)
90 Torque command 16 0 to ±16384
131 Load meter data 16 LM pin
117 Position error 32 Number of erroneous pulses (position
coder orientation)
Data between the spindle and CNC
74 Speed command data 16 ±16384 for the maximum speed command
77 Spindle control signal 1 16 See the command signal from the PMC to
spindle in (4).
54 Load meter data 16 ±16384 for maximum output
55 Motor speed data 16 ±16384 for maximum speed
61 Spindle status signal 1 16 See the status signal from the spindle to
PMC in (4).
78 Spindle control signal 2 16 See the command signal from the PMC to
spindle in (4).
62 Spindle status signal 2 16 See the status signal from the spindle to
PMC in (4).
Other data
34 Phase U current (A/D
conversion data)
16 10 V/FS by shifting 8 bits left(Note)
35 Phase V current (A/D
conversion data)
16
39 DC link voltage 16 1000 V/FS by shifting 8 bits left(Note)
NOTE
Internal data conversion is performed as shown in
the Table in (3).
