3. TROUBLESHOOTING
AND ACTION TROUBLESHOOTING B-65165E/02
- 172 -
(c) A power element is destroyed.
A power element (IGBT, IPM) may be destroyed. Replace
the SPM.
If the amplifier setting condition is not satisfied, or cooling is
insufficient because the heat sink is dirty, the power
elements may be destroyed.
When the heat sink on the back of the amplifier is too dirty,
clean the heat sink, for example, by blowing air. Consider
the use of a structure that prevents the heat sink from being
directly exposed to coolant.
For the setting condition, refer to "FANUC SERVO
AMPLIFIER α series Descriptions (B-65162E)."
3.4.3.2 Alarm code 35
The motor speed calculated from the position coder much differs from
the motor speed estimated in the SPMC.
(1) If this alarm is issued when a rotation command is specified
(a) The setting of parameters for position coder setting is
incorrect.
Set the bits related to the rotation directions of the position
coder and spindle and the rotation directions of the spindle
and motor. For details, refer to "FANUC AC SPINDLE
MOTOR α series Parameter Manual (B-65160E)."
(b) The setting of parameters for gear ratio setting is incorrect.
Check if incorrect gear ratio data is set. The gear ratio data is
used for conversion from the position coder to a motor speed.
So, be sure to set correct values.
FS0 FS15i FS16i/16, PM-D/F Description
6556
to
6559
3056
to
3059
4056
to
4059
Gear ratio between the spindle and
motor
(c) Slippage between the spindle and motor
Make an adjustment to prevent the belt from slipping.
(2) If this alarm is issued during cutting
The motor speed is decreased because of an overload. Review the
cutting condition.
