3. TROUBLESHOOTING
AND ACTION TROUBLESHOOTING B-65165E/02
- 118 -
3.1.1.4 Alarm code 04
(1) Meaning
In the main circuit, the DC voltage (DC link) has dropped.
(2) Cause and troubleshooting
(a) A small power dip has occurred.
→ Check the power supply.
(b) Low input power supply voltage
→ Check the power supply specification.
(c) The main circuit power supply may have been switched off
with an emergency stop state released.
→ Check the sequence.
3.1.1.5 Alarm code 05
(1) Meaning
(a) The input power supply is abnormal (open phase).
(b) The main circuit capacitor was not recharged within the
specified time.
(2) Cause and troubleshooting
(a) The input power supply has an open phase.
→ Check the connection.
(b) Too many SVM and/or SPM units are connected.
→ Check the specification of the PSM.
(c) The DC link is short-circuited.
→ Check the connection.
(d) The recharge current limiting resistor is defective.
→ Replace the unit.
3.1.1.6 Alarm code 06
(1) Meaning
The input power supply is abnormal (open phase).
(2) Cause and troubleshooting
(a) The input power supply has an open phase.
→ Check the connection.
