2. CONFIGURATIONS START-UP PROCEDURE B-65165E/02

- 14 -

2.2.3 Spindle Amplifier Modules

2.2.3.1 α series spindle amplifier modules

The order specification varies according to the detector (function)

used.

(1) α series spindle amplifier modules (SPM) type 1 (standard

specification)

New specification (supporting spindle HRV control), CE-marked

products

Model Order specification Unit specification

Wiring board

specification

Printed circuit

board

specification

ROM (series)

SPM-2.2 A06B-6102-H202#H520 A06B-6102-H202 A16B-2202-0680 A16B-2203-0500

SPM-5.5 A06B-6102-H206#H520 A06B-6102-H206 A16B-2202-0681

SPM-11 A06B-6102-H211#H520 A06B-6102-H211 A16B-2202-0682

A16B-2203-0501

SPM-15 A06B-6102-H215#H520 A06B-6102-H215

A20B-1006-0486

A20B-2902-0390

SPM-22 A06B-6102-H222#H520 A06B-6102-H222

A20B-1006-0487

A20B-2902-0390

SPM-26 A06B-6102-H226#H520 A06B-6102-H226

A20B-1006-0488

A20B-2902-0390

SPM-30 A06B-6102-H230#H520 A06B-6102-H230

A20B-1006-0489

A20B-2902-0390

SPM-45 A06B-6102-H245#H520 A06B-6102-H245

A20B-1007-0591

A20B-2002-0080

SPM-55 A06B-6102-H255#H520 A06B-6102-H255

A20B-1007-0590

A20B-2002-0081

A16B-2203-0502

A06B-6102-H520

(9D20)
