Servo Motor Alpha Series Maintenance manual Page 151

Maintenance manual
3. TROUBLESHOOTING
B-65165E/02 TROUBLESHOOTING AND ACTION
- 123 -
3.1.2.12 Alarm code 17
(1) Meaning
In the main circuit, the voltage at the DC link is abnormally high.
A fuse of the AC reactor unit may have blown.
(2) Cause and troubleshooting
(a) An input fuse of the AC reactor unit has blown.
→ Replace the fuse.
(b) Regeneration circuit failure
→ Replace the unit.
3.1.2.13 Alarm code 08
(1) Meaning
The offset of the current detection circuit of the main circuit DC
link is excessive.
(2) Cause and troubleshooting
(a) The current detection circuit of the main circuit DC link
malfunctions.
→ Replace the power printed wiring board.
(b) The control printed circuit board or A/D converter is faulty.
→ Replace the control printed circuit board.
3.1.2.14 Alarm code 18
(1) Meaning
An error occurred in internal parameter data transfer processing.
(2) Cause and troubleshooting
(a) The control printed circuit board is faulty.
→ Replace the control printed circuit board.
