2. SPINDLE MOTOR

B-65165E/02 MOTOR MAINTENANCE MAINTENANCE

- 229 -

(2) Checking the insulation between the winding and frame

Use a megohmmeter to measure the insulation resistance on 500

VDC. From the measurement result, determine whether the

insulation is acceptable or not according to the following criteria:

• More than 100 MΩ: Acceptable

• 10 to 100 MΩ: Deterioration has started. Although there is no

performance problem, periodic check is required.

• 1 to 10 MΩ: Deterioration is in an advanced state. Special

care must be taken. Periodic check is required.

• Less than 1 MΩ: Unacceptable. Replace the motor.

CAUTION

1 Before measuring insulation resistance, disconnect

the connection to the spindle amplifier module. If

insulation resistance is measured with the spindle

amplifier module connected, the spindle amplifier

module may be damaged.

2 During the measurement of insulation resistance,

applying voltage to the motor for a long time may

further deteriorate the insulation of the motor.

Therefore, the measurement of insulation resistance

should be performed in a minimum amount of time

where possible.
