3. TROUBLESHOOTING

B-65165E/02 TROUBLESHOOTING AND ACTION

- 151 -

3.4.1.10 Alarm code 13

The memory inside the CPU is faulty. A check is made when the power

is turned on.

If this alarm is issued, replace the SPM or SPM control printed circuit

board.

3.4.1.11 Alarm code 15

In output switching control or spindle switching control, the switching

operation sequence was not executed correctly.

This alarm is issued if one second or more elapses from the transition of

a switch request signal (SPSL or RSL) until a power line state check

signal (MCFN, MFNHG, RCH, or RCHHG) makes a transition.

Troubleshooting when this alarm is issued

(a) The magnetic contactor (switch unit) for power line

switching is faulty.

If the contact is inoperative, check the power supply of the

magnetic contactor. If the magnetic contactor is still

inoperative, replace the magnetic contactor.

(b) The I/O unit or wiring for checking the contact of the

magnetic contactor is faulty.

If a defect is found in the I/O unit or wiring, replace the I/O

unit or wiring.

Modify the sequence so that switching is completed within 1

second. For details of the signals, refer to Chapter 10,

"Interface Signals," in "FANUC SERVO AMPLIFIER α series

Descriptions (B-65162E)."

3.4.1.12 Alarm code 16

The memory (RAM) is faulty. A check is made when the power is

turned on.

If this alarm is issued, replace the SPM or SPM control printed circuit

board.
