Servo Motor Alpha Series Maintenance manual Page 131

Maintenance manual
2. ALARM NUMBERS AND
B-65165E/02 TROUBLESHOOTING BRIEF DESCRIPTIONS
- 103 -
Alarm
No.
SVM SPM PSM Description Remarks
SV0442 05 Converter: DC link charging/inverter DB 3.1
SV0443 02 Converter: cooling fan stopped 3.1
SV0444 1 Inverter: internal cooling fan stopped 3.2
SV0445 Soft disconnection alarm 3.3.4
SV0446 Hard disconnection alarm Not
issued
SV0447 Hard disconnection alarm (separate) 3.3.4
SV0448 Feedback mismatch alarm 3.3.8
SV0449 8.
9.
A.
b.
C.
d.
E.
Inverter: IPM alarm (L axis)
(M axis)
(N axis)
(L and M axes)
(M and N axes)
(L and N axes)
(L, M, and N axes)
3.2
Spindle alarm
Alarm
No.
SVM SPM PSM Description Remarks
SP097x A Program ROM error 3.4
SP097x A0 Program ROM error 3.4
SP097x A1 Program RAM error 3.4
SP097x A2 Program RAM error 3.4
SP097x A3 SPM control circuit clock error 3.4
SP097x A4 SRAM parity error 3.4
SP0001 01 Motor overheat 3.4
SP0002 02 Excessive speed deviation 3.4
SP0003 03 DC link fuse blown 3.4
SP0004 04 06 Power supply failure 3.4
SP0007 07 Excessive speed 3.4
SP0009 09 Main circuit overload 3.4
SP0011 11 07 DC link overvoltage 3.4
SP0012 12 DC link overcurrent/IPM alarm 3.4
SP098x 13 CPU internal data memory error 3.4
SP0015 15 Output switching/spindle switching alarm 3.4
SP098x 16 RAM error 3.4
SP098x
19 Excessive offset of the phase U current
detection circuit
3.4
SP098x
20 Excessive offset of the phase V current
detection circuit
3.4
SP022x 24 Serial transfer data error 3.4
SP022x 25 Serial data transfer stopped 3.4
