7 For stand–alone type LCD or stand–alone type MDI, video cable J136
or stand–alone type LCD power cable J137 are not supplied with the
unit.
8 Always connect the protective ground plates of the LCD/MDI,
stand–alone type LCD, and stand–alone type MDI to ground, see
Section 5.8.
9 External dimension of LCD/MDI is same as it of CRT/MDI.
10 If the ambient temperature is low, the brightness of the LCD decreases
(immediately after the power is turned on, in particular). This is due
to the characteristics of the LCD, and does not indicate a fault. As the
ambient temperature rises, the LCD becomes brighter.
11 All interfaces not described here are the same as those of the
CRT/MDI.
NOTE
Even if only one Power Mate unit is connected, connection
must be made through the device number selection switch
interface.
