Power Mate i - Model D/H Connection manual (Hardware) Page 268

Connection manual (Hardware)
8. CONNECTION TO SETTING AND DISPLAY UNIT
B–63173EN/03
256
Device No. *SEL7 *SEL4 *SEL3 *SEL2 *SEL1 *SEL0
#15 ĘĘĘ
#0
#1 Ę
#2 Ę
#3 Ę
#4 Ę
#5 Ę Ę
#6 Ę Ę
#7 ĘĘ
#8 Ę
#9 Ę Ę
#10 Ę Ę
#11 Ę Ę
#12 ĘĘ
#13 ĘĘ Ę
#14 ĘĘ Ę
Common
display Ę ** ***
Recommended cable:
A66L–0001–0284#10P (#28AWG10 ten pairs)
Recommended connector
PCR–E20FS or PCR–E20FA
Housing PCR–V20LA
Maximum cable length : 10m
Relationship between selection
switches and device numbers
: Switch open
Ę : Switch closed
* : Either will do
Recommended cable:
A66L–0001–0284#10P (#28AWG10 ten pairs)
The stand–alone type LCD is provided with the following adjustment
switch and potentiometers, the factory settings of which must not be
changed. (Adjustment is necessary only when the unit has been
disassembled to replace the adapter or LCD panel.)
VR1 : Flicker adjustment potentiometer
VRP1: Contrast adjustment potentiometer
SW1 : Horizontal position adjustment switch
8.4.4
Adjusting the
Stand–Alone Type LCD
