B-65325EN/01 START-UP PROCEDURE FOR βi SVPM 4.CONFIRMATION OF THE OPERATION
- 109 -
Method of using the servo check board
For details on how to connect and use the servo check board, refer to
the following:
Section 4.18 in the FANUC AC SERVO MOTOR αis/αi/βis series
Parameter Manual (B-65270EN)
- Required units
• Servo check board
A06B-6057-H630
• Oscilloscope
- Settings
⋅
⋅⋅
⋅ CNC setting
Parameter setting for servo software series 90B0
Output channel
Data number 5
Data number 6
FS16i/18i/21i/0i/PMi
No.2115 No.2151 No.2152 No.2153
Measurement axis/
current phase
IR IS
L-axis
(Note 1)
370 0 402 0
M-axis
(Note 1)
2418 0 2450 0
Parameter setting for servo software series 9096
Output channel
Data number 5
Data number 6
FS16i/18i/21i/0i/PMi
No.2115 No.2115
Measurement axis/
current phase
IR IS
L-axis
(Note 1)
370 402
M-axis
(Note 1)
1010 1042
When series 9096 is used, if no axis is paired with the measurement
axis
(Note 2)
, IR and IS cannot be observed simultaneously.
NOTE
1 The L-axis is an axis identified with an odd number
set in parameter No. 1023. The M-axis is an axis
identified with an even number set in parameter No.
1023.
2 The axis specified as 2n-1 in parameter No. 1023
and the axis specified as 2n will be in a pair.
