Maintenance manual
3.TROUBLESHOOTING AND ACTION TROUBLESHOOTING FOR βi SVM B-65325EN/01
- 40 -
For SVM1-40i and SVM1-80i
• When the built-in regenerative resistor is used
(a) Connect CXA20 and CZ6 by using a dummy connector.
(b) The average regenerative power may be high. Decrease
the frequency of acceleration/deceleration, or review
the resistor specification.
(c) Insert the SVM face plate (control printed-circuit
board) securely.
(d) Replace the SVM.
• When a separate regenerative resistor is used
(a) Check the resistance at both ends of connector CXA20
on the regenerative resistor side to confirm that the
resistance is 0 Ω.
(b) The average regenerative power may be high. Decrease
the frequency of acceleration/deceleration, or review
the resistor specification.
(c) Insert the SVM face plate (control printed-circuit
board) securely.
(d) Replace the SVM.
3.1.4 Converter: Control Power Supply Undervoltage
(1) Meaning
The external control power supply (24 VDC) voltage is low.
(2) Cause and troubleshooting
(a) Check the voltage level of the external power supply (24
VDC). (Normal voltage: 21.6 V or higher)
(b) Check the connector and cable (CXA19A, CXA19B).
(c) Replace the SVM.
3.1.5 Inverter: Internal Cooling Fan Stopped
(1) Meaning
Inverter: internal cooling fan stopped
(2) Cause and troubleshooting
(a) Check whether there is any foreign material in the fan.
(b) Be sure to push the faceplate (control printed-circuit board)
as far as it will go.
(c) Check that the fan connector is attached correctly.
(d) Replace the fan.
(e) Replace the SVM.
