4.CONFIRMATION OF THE OPERATION START-UP PROCEDURE FOR βi SVM B-65325EN/01
- 18 -
- Display
Select the XTYT mode from the graph window mode (M) menu to
display waveforms.
Method of using the servo check board
For details on how to connect and use the servo check board, refer to
the following manual:
FANUC AC SERVO MOTOR αis/αi/βis series Parameter Manual
(B-65270EN)
- Required units
• Servo check board
A06B-6057-H630
• Oscilloscope
- Settings
⋅
⋅⋅
⋅ CNC setting
Parameter setting for servo software series 90B0
Output channel
Data number 5
Data number 6
FS15i
No.1726 No.1774 No.1775 No.1776
FS16i/18i/21i/0i/PMi
No.2115 No.2151 No.2152 No.2153
Measurement axis/
current phase
IR IS
L-axis
(Note 1)
370 0 402 0
M-axis
(Note 1)
2418 0 2450 0
Parameter setting for servo software series 9096
Output channel
Data number 5
Data number 6
FS16i/18i/21i/0i/PMi
No.2115 No.2115
Measurement axis/
current phase
IR IS
L-axis
(Note 1)
370 402
M-axis
(Note 1)
1010 1042
When series 9096 is used, if no axis is paired with the measurement
axis
(Note 2)
, IR and IS cannot be observed simultaneously.
NOTE
1 The L-axis is an axis identified with an odd number
set in parameter No. 1023. The M-axis is an axis
identified with an even number set in parameter No.
1023.
2 The axis specified as 2n-1 in parameter No. 1023
and the axis specified as 2n will be in a pair.
