Maintenance manual
B-65325EN/01 TROUBLESHOOTING FOR βi SVPM 2.ALARM NUMBERS AND BRIEF DESCRIPTIONS
- 127 -
Servo
alarm
Spindle
alarm
Spindle
alarm
STATUS1
Spindle unit
STATUS2
Servo unit
Description Remarks
9084 7n84 84 Spindle sensor disconnected 3.4.32
9085 7n85 85
Spindle sensor one-rotation signal detection
error
3.4.33
9086 7n86 86
Spindle sensor one-rotation signal not
detected
3.4.34
9087 7n87 87 Spindle sensor signal error 3.4.35
7n97 Other spindle amplifier alarm
7n98 Other converter alarm
749 749 A Program ROM error 3.4.36
749 749 A1 Program ROM error 3.4.36
749 749 A2 Program ROM error 3.4.36
9110 7n98 b0
Communication error between amplifier and
module
Not issued.
432 9111 7n98 b1 Converter: control power supply low voltage 3.1.6
9120 C0 Communication data alarm 3.4.37
9121 C1 Communication data alarm 3.4.37
9122 C2 Communication data alarm 3.4.37
* n represents a spindle number.
