3.TROUBLESHOOTING AND ACTION TROUBLESHOOTING FOR βi SVM B-65325EN/01
- 38 -
3.1 SERVO AMPLIFIER MODULE
The following table lists alarms related to the servo amplifier module.
See this table and the CNC alarm code indicated in Chapter 2,
"ALARM NUMBERS AND BRIEF DESCRIPTIONS".
Alarm
LED
display
Major cause Reference
Converter: DC link undervoltage ON Voltage drop at the DC link in the main circuit 3.1.1
Converter: DC link overvoltage ON Voltage rise at the DC link in the main circuit 3.1.2
Converter: excessive deceleration
power
ON - Too large regenerative discharge amount
- Abnormal regenerative discharge circuit
3.1.3
Converter: control power supply
undervoltage
ON - Drop in external control power supply (24 V)
- Connector/cable (CXA19A, CXA19B) defective
- SVM failure
3.1.4
Inverter: internal cooling fan stopped ON
- Fan not running.
- Fan motor connector or cable defective
- SVM failure
3.1.5
Inverter: cooling fan stopped of the
radiator
ON
- Fan not running.
- Fan motor connector or cable defective
- SVM failure
3.1.6
Inverter: IPM alarm ON
- Short-circuit between power lead phases or ground fault
in them
- Short-circuit between motor winding phases or ground
fault in them
- SVM failure
3.1.7
Inverter: IPM alarm (OH) ON
- The motor is being used under a harsh condition.
- The ambient temperature is high.
- SVM failure
3.1.8
Inverter: motor current alarm ON
- Short-circuit between power lead phases or ground fault
in them
- Short-circuit between motor winding phases or ground
fault in them
- Incorrect motor ID setting
- SVM or motor failure
3.1.9
Inverter: FSSB communication error ON
- Connector or cable failure
- SVM or CNC failure
3.1.10
