Maintenance manual
3.TROUBLESHOOTING AND ACTION TROUBLESHOOTING FOR βi SVPM B-65325EN/01
- 146 -
Action 2: This alarm is issued when the difference between the motor
position and separate detector position exceeds the
excessive semi-full error level. Check if the conversion
efficient for dual position feedback is set correctly. If the
conversion efficient is set correctly, increase the alarm
level. If this alarm is still issued after the level is modified,
check the connection direction of the scale.
No. 2078 (FS0i)
Dual position feedback conversion coefficient (numerator)
No. 2079 (FS0i)
Dual position feedback conversion coefficient (denominator)
Conversion coefficient =
N
umbe
r
of feedback pulses per motor
revolution (detection unit)
1,000,000
No. 2118 (FS0i)
Dual position feedback semi-full error level
[Setting] Detection unit. When 0 is set, no detection is made.
Action 3: The current offset value of the current detector (equivalent
to the current value in the emergency stop state) is
abnormally high. If this alarm is still issued after the power
is turned off then back on, the current detector is faulty.
Replace the SVPM.
