B-65325EN/01 TROUBLESHOOTING FOR βi SVPM 3.TROUBLESHOOTING AND ACTION
- 133 -
3.2.1 STATUS2 Alarm Code 2
(1) Meaning
Inverter: control power supply undervoltage
(2) Cause and troubleshooting
(a) Check the three-phase input voltage of the amplifier (the
voltage shall not be lower than 85% of the rated input
voltage).
(b) Check the 24 V power supply voltage output from the SVPM
(the voltage shall normally not lower than 22.8 V).
(c) Check the connector and cable (CXA2A/B).
(d) Replace the SVPM.
3.2.2 STATUS2 Alarm Code 5
(1) Meaning
Inverter: DC link undervoltage
(2) Cause and troubleshooting
(a) The three-phase input voltage level drops.
(b) Replace the control printed circuit board.
(c) Replace the SVPM.
3.2.3 STATUS2 Alarm Code 6
(1) Meaning
Inverter: overheat
(2) Cause and troubleshooting
(a) Check that the motor is being used at or below its continuous
rating.
(b) Check that the cooling capacity of the cabinet is sufficient
(inspect the fans and filters).
(c) Check that the ambient temperature is not too high.
(d) Be sure to push the faceplate (control printed-circuit board)
as far as it will go.
(e) Replace the SVPM.
3.2.4 STATUS2 Alarm Code P
(1) Meaning
Communication error between amplifier modules
(2) Cause and troubleshooting
(a) Check the connector and cable (CXA2A/B).
(b) Replace the control printed-circuit board.
(c) Replace the SVPM.
Previous page
Next page
