Maintenance manual
B-65325EN/01 TROUBLESHOOTING FOR βi SVPM 3.TROUBLESHOOTING AND ACTION
- 153 -
3.4.11 Alarm Code 24
Serial communication data transferred between the CNC and SVPM
contains an error.
(Note)
Troubleshooting when this alarm is issued
(a) Noise occurring between the CNC and SVPM (connected via an
electric cable) caused an error in communication data.
Check the condition for maximum wiring length.
(b) Noise exercises an influence because a communication cable is
bundled with the power lead.
If a communication cable is bundled with the power lead for the
motor, separate them from each other.
(c) A cable is faulty.
Replace the cable.
If an optical I/O link adapter is used, the optical link adapter or
optical cable may be faulty.
(d) The SVPM is faulty.
Replace the SVPM or SVPM control printed circuit board.
(e) The CNC is faulty.
Replace the board or module related to the serial spindle.
NOTE
This alarm is issued also if the CNC power is off.
This is not a failure, though.
