B-65325EN/01 TROUBLESHOOTING FOR βi SVM 2.ALARM NUMBERS AND BRIEF DESCRIPTIONS
- 35 -
2.1 FOR Series 15i
2.1.1 Servo Alarm
Alarm No. Description Remark
SV0027 Invalid digital servo parameter setting 3.2.6
SV0361 Pulsecoder phase error (built-in) 3.2.7 (1)
SV0364 Soft phase alarm (built-in) 3.2.7 (1)
SV0365 LED error (built-in) 3.2.7 (1)
SV0366 Pulse error (built-in) 3.2.7 (1)
SV0367 Count error (built-in) 3.2.7 (1)
SV0368 Serial data error (built-in) 3.2.7 (3)
SV0369 Data transfer error (built-in) 3.2.7 (3)
SV0380 LED error (separate) 3.2.7 (2)
SV0381 Pulsecoder phase error (separate) 3.2.7 (2)
SV0382 Count error (separate) 3.2.7 (2)
SV0383 Pulse error (separate) 3.2.7 (2)
SV0384 Soft phase alarm (separate) 3.2.7 (2)
SV0385 Serial data error (separate) 3.2.7 (3)
SV0386 Data transfer error (separate) 3.2.7 (3)
SV0387 Sensor error (separate) 3.2.7 (2)
SV0421 Excessive semi-full error 3.2.8
SV0430 Servo motor overheat 3.2.5
SV0432 Converter: control power supply
undervoltage
3.1.4
SV0433 Converter: DC link undervoltage 3.1.1
SV0436 Soft thermal (OVC) 3.2.3
SV0438 Inverter: motor current alarm 3.1.9
SV0439 Converter: DC link overvoltage 3.1.2
SV0440 Converter: Excessive deceleration power 3.1.3
SV0441 Current offset error 3.2.8
SV0444 Inverter: internal cooling fan stopped 3.1.5
SV0445 Soft disconnection alarm 3.2.4
SV0447 Hard disconnection alarm (separate) 3.2.4
SV0448 Feedback mismatch alarm 3.2.8
SV0449 Inverter: IPM alarm 3.1.7
SV0601 Inverter: cooling fan stopped of the radiator 3.1.6
SV0603 Inverter: IPM alarm (OH) 3.1.8
