10. TOOL FUNCTIONS

B–63502EN/01

NC FUNCTION

The following features are added to the tool life management function for

easier handling:

D Setting tool life management data for each tool group by program

Addition, modification, and deletion can be made to only the tool life

management data of a specified group; the tool life management data

of the other groups is left intact.

A tool life is set for each tool group by time or use count.

D Displaying and editing tool life management data

All tool life management data is displayed on the screen, and so the

user can understand the current tool state instantly. The following data

items are displayed:

- Tool group number of the tool currently used

- Tool group number selected next

Life, life counter value

List of tool numbers in the group

Cutter compensation number and tool

length compensation corresponding to

each tool number

Use state for each tool (for example,

indicating whether tool life is reached)

- Tool life

management

data

Tool life management data can be modified at the MDI panel. In

addition, tool numbers can be added, changed, and deleted.

D Life count override

If a tool life is set by time, actual time obtained by multiplying the use

time of a tool by a magnification (override value) can be added to the

life counter. An override value from 0 to 99.9 is specified in steps of

0.1 by a signal sent from the PMC.

Example)

If the override value is 0.1, and the use time of a tool is ten minutes,

the life counter is incremented by one minute.

M series10.2.2

Extended Tool Life

Management

(M series)
