Series 0i - Model A Descriptions Page 45

Descriptions
B–63502EN/01
1. CONTROLLED AXES
NC FUNCTION
21
The following least input increments can be set using a parameter:
Increment system Least input increment
IS–B 0.01 mm, 0.01 deg, or 0.0001 inch
IS–C 0.001 mm, 0.001 deg, or 0.00001 deg
NOTE
The minimum input increment for inch input is not affected.
The following table lists the maximum strokes of machine tools that are
allowed by the control unit:
Maximum stroke = Least command increment 99999999
Increment system Maximum stroke
Millimeter machine
±99999.999 mm
±99999.999 deg
IS–B
Inch machine
±9999.9999 inch
±99999.999 deg
Millimeter machine
±9999.9999 mm
±9999.9999 deg
IS–C
Inch machine
±999.99999 inch
±9999.9999 deg
NOTE
1 The values (in mm or inches) in the table are diameter
values if diameter programming is specified, or radius
values if radius programming is specified.
2 A command that exceeds the maximum stroke is not
allowed.
1.4.1
Input Unit (10 Times)
1.5
MAXIMUM STROKE
