Series 0i - Model A Descriptions Page 50

Descriptions

Page of 328

/ 328

2. PREPARATORY FUNCTIONS

B–63502EN/01

NC FUNCTION

The following G codes are provided :

G code list for M series (1/3)

G code Group Function

G00

Positioning

G01

Linear interpolation

G02

Circular interpolation/Helical interpolation CW

G03 Circular interpolation/Helical interpolation CCW

G04 Dwell, Exact stop

G05.1 Look–ahead control (Multiple blocks are read in advance.)

G07 Hypothetical axis interpolation

G07.1 (G107) Cylindrical interpolation

G08

Look–ahead control

G09 Exact stop

G10 Programmable data input

G11 Programmable data input mode cancel

G15

Polar coordinates command cancel

G16

Polar coordinates command

G17

XpYp plane selection Xp: X axis or its parallel axis

G18 02

ZpXp plane selection Yp: Y axis or its parallel axis

G19 YpZp plane selection Zp: Z axis or its parallel axis

G20 Input in inch

G21

Input in mm

G22

Stored stroke check function on

G23

Stored stroke check function off

G27 Reference position return check

G28 Return to reference position

G29 00 Return from reference position

G30 2nd, 3rd and 4th reference position return

G31 Skip function

G33 01 Thread cutting

G37 Automatic tool length measurment

G39

Corner offset circular interpolation

G40

Cutter compensation cancel

G41

Cutter compensation left

G42 Cutter compensation right

2.2

M SERIES
