1. CONTROLLED AXES

B–63502EN/01

NC FUNCTION

There are two increment systems as shown in the tables below. One of the

increment systems can be selected using a parameter.

Table 1.4(a) IS–B

Least input increment

Least

command

increment

Abbreviation

0.001 mm (diameter programming) 0.0005 mm

Metric input 0.001 mm (radius programming) 0.001 mm

0.001 deg 0.001 deg

0.0001 inch (diameter programming) 0.0005 mm

Inch input 0.0001 inch (radius programming) 0.001 mm

Millimeter

0.001 deg 0.001 deg

Millimeter

machine

0.001 mm (diameter programming) 0.00005 inch

IS–B

Metric input 0.001 mm (radius programming) 0.0001 inch

0.001 deg 0.001 deg

0.0001 inch (diameter programming) 0.00005 inch

Inch input 0.0001 inch (radius programming) 0.0001 inch

0.001 deg 0.001 deg

Table 1.4(b) IS–C

Least input increment

Least

command

increment

Abbreviation

0.0001 mm (diameter programming) 0.00005 mm

Metric input 0.0001 mm (radius programming) 0.0001 mm

Millimeter

0.0001 deg 0.0001 deg

Millimeter

machine

0.00001 inch (diameter programming) 0.00005 mm

Inch input 0.00001 inch (radius programming) 0.0001 mm

0.0001 deg 0.0001 deg

0.0001 mm (diameter programming) 0.000005 inch

IS–C

Metric input 0.0001 mm (radius programming) 0.00001 inch

Millimeter

0.0001 deg 0.0001 deg

Millimeter

machine

0.00001 inch (diameter programming) 0.000005 inch

Inch input 0.00001 inch (radius programming) 0.00001 inch

0.0001 deg 0.0001 deg

The least command increment is in millimeters or inches, depending on

the machine tool. One of them must be selected using a parameter

beforehand.

The least input increment can be switched between metric input and inch

input by using a G code (G20 or G21) or a setting parameter.

1.4

INCREMENT SYSTEM
