Series 0i - Model A Descriptions Page 153

Descriptions
B–63502EN/01
13. FUNCTIONS TO SIMPLIFY
PROGRAMMING
NC FUNCTION
129
Angles of straight lines, chamfering values, corner rounding values, and
other dimensional values on machining drawings can be programmed by
directly inputting these values. In addition, the chamfering and corner
rounding can be inserted between straight lines having an arbitrary angle.
The straight line angle, chamfering value, or corner rounding must be
specified with a comma as follows:
,A_
,C_
,R_
NOTE
When A or C is not used as an axis name, the line angle,
chamfering value, or corner rounding can be specified in the
parameter without comma as follows:
A_
C_
R_
(X
1
, Z
1
)
(X
2
, Z
2
)
A
X
Z
Command
(X
1
, Z
1
)
(X
3
, Z
3
)
(X
2
, Z
2
)
X
Z
A
1
A
2
(X
1
, Z
1
)
(X
3
, Z
3
)
(X
2
, Z
2
)
X
Z
A
1
A
2
R
1
X
2_
(Z
2_
), A_ ;
, A
1
_ ;
X
3
_ Z
3
_, A
2
_ ;
X
2
_ Z
2
_, R
1
_ ;
X
3
_ Z
3
_ ;
or
, A
1
_, R
1
_ ;
X
3
_ Z
3
_, A
2
_ ;
1
2
3
Movement of tool
13.8
DIRECT DRAWING
DIMENSIONS
PROGRAMMING
(T series)
T series
