27. PART PROGRAM STORAGE

AND EDITING

NC FUNCTION

235

The following two screens can be displayed with graphic data for

guidance in programming in the CNC format:

D G code list

D Standard format of a G-code block

Programs can be created by referring to guidelines and entering necessary

data interactively.

O0010 N00000

G00 :

G01 :

G02 :

G03 :

G04 :

G10 :

G20 :

G21 :

G25 :

G26 :

G27 :

G28 :

EDIT **** *** *** 11:42:31

[ ][ ][ ][ ][ ]

↓ When G01 is selected

PROGRAM O0010 N00000

G01 :

G01 G G G

X U

Z W

;

EDIT **** *** *** 11:56:41

[ ][ ][ ][ ][ ]

(X,Z)

The password function (parameter NE9) can be locked using parameter

PASSWD and parameter KEYWD to protect program Nos. 9000 to 9999.

In the locked state, parameter NE9 cannot be set to 0. In this state,

program Nos. 9000 to 9999 cannot be modified unless the correct

keyword is set.

A locked state means that the value set in the parameter PASSWD differs

from the value set in the parameter KEYWD. The values set in these

parameters are not displayed. The locked state is released when the value

already set in the parameter PASSWD is also set in parameter KEYWD.

When 0 is displayed in parameter PASSWD, parameter PASSWD is not

set.

27.8

CONVERSATIONAL

PROGRAMMING OF

FIGURES

27.9

PASSWORD

FUNCTION
