Series 0i - Model A Descriptions Page 250

Descriptions

Page of 328

/ 328

26. DISPLAYING AND SETTING DATA

B–63502EN/01

NC FUNCTION

226

The configurations of software and hardware required for maintenance of

the CNC are displayed.

The system configuration display function provides the following three

screens:

D Slot information screen

D Software information screen

D Hardware (module) information screen

SYSTEM CONFIG O1234 N56789

PAGE:01

SLOT MODULE_ID SERIES VERSION

00 01D9 :40 D401 0001

02 023F :4A B401 0013

MEM **** *** *** 18:46:43

[ PARAM ][ DGNOS ][ PMC ][ SYSTEM ][ ]

  

 Slot No.

 Module ID

 Software ID

 Software series

 Software edition

SYSTEM CONFIG(SOFTWARE) O1234 N56789

PAGE:02

SYSTEM D401 0001

BASIC+OPTION–A1

SERVO 9066 0011

PMC 4098 0001

LADDER TEST 0001

MACRO LIB DZ81 0001

MACRO APL AAAA 0001

GRAPHIC 600R 0001

BOOT 60M4 0001

PMM 8A00 0005

MEM **** *** *** 19:14:23

[ PARAM ][ DGNOS ][ PMC ][ SYSTEM ][ ]









 Software type

 Software series

 Software edition

 Contents of ROM (system ROM only)

26.10

SYSTEM

CONFIGURATION

DISPLAY FUNCTION

Slot information

Software information
