Series 0i - Model A Descriptions Page 207

Descriptions
B–63502EN/01
20. FUNCTIONS FOR HIGH SPEED
CUTTING
NC FUNCTION
183
This function reads one block in advance to achieve high–speed
high–precision machining. With this function, the delay due to
acceleration/deceleration and the delay in the servo system which
increase as the feedrate becomes higher can be suppressed.
The tool can then follow specified values accurately and errors in the
machining profile can be reduced.
This function becomes effective when look–ahead control mode is
entered.
G08 P_ ;
P1 : Turn on look–ahead control mode.
P0 : Turn off look–ahead control mode.
In look–ahead control mode, the following functions are available :
D Linear acceleration/deceleration before interpolation
D Automatic corner deceleration function
20.3
LOOK–AHEAD
CONTROL (G08)
(M series)
M series
Format
Previous page
Next page
