B–63502EN/01

2. LIST OF SPECIFICATIONS

GENERAL

Item

Series 0i

SpecificationsItem

TAMA

Specifications

Follow–up f f

Servo off/mechanical handle feed f f

Chamfering on/off — f

Backlash compensation f f

Backlash compensation for each rapid traverse

and cutting

f f

Stored pitch error compensation f f

Position switch f f

Unexpected disturbance torque detection

function

f f

Operation

Automatic operation (memory) f f

DNC operation f f

MDI operation f f

Schedule function f f

Program number search f f

Sequence number search f f

Sequence number comparison and stop f f

Program restart f f

Manual intervention and return f f

Retraction for rigid tapping f —

Buffer register f f

Dry run f f

Single block f f

JOG feed f f

Manual reference position return f f

Reference position setting without DOG f f

Reference position setting with mechanical

stopper

f f

Reference position shift f —

1 unit/each path f f

Manual handle feed

2 units — f

2 units/3 units f —

Manual handle feed rate

x1, x10, xm, xn

m: 0–127, n: 0–1000

f f

Manual handle interruption f f

Incremental feed x1, x10, x100, x1000 f f

Jog and handle simultaneous mode f f

Interpolation functions

Positioning

G00 (Linear interpolation type positioning

is possible)

f f

Single direction positioning G60 f —

Exact stop mode G61 f —

Exact stop G09 f —

Linear interpolation G01 f f

Circular interpolation G02/G03 (Multi–quadrant) f f

Dwell G04 f f

Polar coordinate interpolation — f

Cylindrical interpolation f f
