B–63502EN/01

2. PREPARATORY FUNCTIONS

NC FUNCTION

The following G codes are provided. The G codes are classified into

three: A, B, and C. One of the G code types can be selected using a

parameter. In this manual, G code system B is assumed.

G code list for T series (1/3)

G code

A B C

Group Function

G00 G00 G00 Positioning (Rapid traverse)

G01 G01 G01 Linear interpolation (Cutting feed)

G02 G02 G02

Circular interpolation CW or Helical interpolation CW

G03 G03 G03 Circular interpolation CCW or Helical interpolation CCW

G04 G04 G04 Dwell

G07.1

(G107)

G07.1

(G107)

G07.1

(G107)

Cylindrical interpolation

G10 G10 G10

Programmable data input

G11 G11 G11 Programmable data input mode cancel

G12.1

(G112)

G12.1

(G112)

G12.1

(G112)

Polar coordinate interpolation mode

G13.1

(G113)

G13.1

(G113)

G13.1

(G113)

Polar coordinate interpolation cancel mode

G17 G17 G17 XpYp plane selection

G18 G18 G18 16 ZpXp plane selection

G19 G19 G19 YpZp plane selection

G20 G20 G70 Input in inch

G21 G21 G71

Input in mm

G22 G22 G22 Stored stroke check function on

G23 G23 G23

Stored stroke check function off

G25 G25 G25 Spindle speed fluctuation detection off

G26 G26 G26

Spindle speed fluctuation detection on

G27 G27 G27 Reference position return check

G28 G28 G28 Return to reference position

G30 G30 G30

2nd, 3rd and 4th reference position return

G31 G31 G31 Skip function

G32 G33 G33 Thread cutting

G34 G34 G34

Variable–lead thread cutting

G36 G36 G36 Automatic tool compensation X

G37 G37 G37

Automatic tool compensation Z

G40 G40 G40 Tool nose radius compensation cancel

G41 G41 G41 07 Tool nose radius compensation left

G42 G42 G42 Tool nose radius compensation right

2.1

T SERIES
