30. SAFETY FUNCTIONS

B–63502EN/01

NC FUNCTION

248

Axis feed specified to each axis can be stopped separately. If interlock is

specified to any of the moving axis during cutting feed, all axes of the

machine movement will decelerate to a stop. When interlock signal is

reset, the moving starts.

Feed of all axes can be inhibited. When all axes interlock is commanded

during move, it decelerates and stops. When all axes interlock signal is

reset, the moving restarts.

Feeding of a specific axis in a specific direction can be inhibited

independently of other axes. If the interlock signal is input to any of the

axes during a cutting feed operation, all axes decelerate and come to a

stop. When the interlock signal for each axis direction is released, the axes

start moving again.

Feeding of all axes can be inhibited only during automatic operation.

When the start lock signal is input while the axes are moving, all axes

decelerate and come to a stop. When the start lock signal is released, the

axes start moving again.

30.3

INTERLOCK

30.3.1

Interlock per Axis

30.3.2

All Axes Interlock

30.3.3

Interlock for Each Axis

Direction

30.3.4

Start Lock

T series
