B–63502EN/01

2. LIST OF SPECIFICATIONS

GENERAL

Item

Series 0i

SpecificationsItem

TAMA

Specifications

Multiple command of auxiliary function 3 f f

Spindle speed function S5–digit, binary output f f

Spindle serial output S5–digit, serial output (1st/2nd) F F

Spindle analog output S5–digit, analog output F F

Constant surface speed control f f

Spindle override 0–254% f f

Actual spindle speed output — f

Spindle speed fluctuation detection — f

1st spindle orientation f f

1st spindle output switching function f f

2nd spindle orientation f f

2nd spindle output switching function f f

Spindle synchronous control f f

Multi spindle control — f

Spindle positioning — f

Rigid tapping f f

Tool function/Tool compensation

T7 + 1/T6 + 2 digits — f

Tool function

T8 digits f —

"6 digits 400 f —

Tool offset pairs

"6 digits 32 pairs — f

Tool offset memory C

Distinction between geometry and wear, or

between cutter and tool length

compensation.

f —

Tool length compensation f —

Tool offset f f

Y–axis offset — f

Cutter compensation C f —

Tool nose radius compensation — f

Tool geometry/wear compensation — f

Tool life management f f

Extended tool life management f —

Tool offset value counter input — f

Tool length measurement f —

Automatic tool length measurement f —

Automatic tool offset — f

Direct input of tool offset value measured — f

Direct input of tool offset value measured B — f

Editing operation

160m (equivalent to 64KB)*1 f f

Part program storage length

640m (equivalent to 256KB)*1 l l

Number of registerable programs 200 f f

Part program editing f f

Program protect f f

Background editing f f

Extended part program editing f f

Playback f f

Note) *1 : A slight difference occurs depending on the number of registered programs and their sizes.
