26. DISPLAYING AND SETTING DATA

B–63502EN/01

NC FUNCTION

214

The following data are displayed. Maximum 640 characters (40 × 16

lines) can be displayed.

The status of the control unit is indicated on the screen. Statuses include

the state when an alarm is being activated or when the system is in the edit

mode. The status line is displayed right above the soft key line.

EDIT STOP MTN FIN ALM hh:mm:ss OUTPUT

––EMG––











Status

line

Soft key

line

 Operation mode (MDI, MEM, RMT, EDIT, HND, TJOG, THND,

INC, or REF)

 Status of automatic operation (STOP, HOLD, STRT, or ****)

***** : Reset

STOP : Automatic operation is in a stopped state.

HOLD : Automatic operation is in a halt state.

STRT : Automatic operation has been started.

 Axis movement/dwell (MTN, DWL, or ***)

 FIN wait state (FIN or ***)

 Emergency stop (--EMG--) (displayed above in 3 and 4)

 Alarm status (ALM, WNG, or ***)

 Clock (hh:mm:ss)

 Status display such as program editing (INPUT, OUTPUT, SRCH,

EDIT, LSK, or RSTR)

Data input via the address keys or the numerical keys are displayed at the

left lower part of the screen.

Program number, sequence number is displayed on the right upper part

of the screen.

Alarm number and its contents are displayed briefly.

Alarm message contents are displayed.

Relative position and position in the work coordinates are displayed in

3-times magnified characters.

Relative position, position in the work coordinates, position in the

machine coordinate, and remaining move distance are displayed in one

screen.

26.1

DISPLAY

Explanations

D Indication of statuses

and tool post names

D Key input display

D Program number,

sequence number

display

D Alarm display

D Alarm message display

D Present position display

D Total position display
