Series 0i - Model A Descriptions Page 31

Descriptions

Page of 328

/ 328

B–63502EN/01

2. LIST OF SPECIFICATIONS

GENERAL

Item

Series 0i

SpecificationsItem

TAMA

Specifications

Helical interpolation

Circular interpolation plus max. 2 axes

linear interpolation

f —

Threading, synchronous cutting f f

Multiple threading — f

Threading retract — f

Continuous threading — f

Variable lead threading — f

Polygon turning — f

Skip G31 f f

High–speed skip f f

Torque limit skip — f

Reference position return G28 f f

Reference position return check G27 f f

2nd reference position return G30 f f

3rd/4th reference position return f f

Normal direction control f —

Index table indexing f —

Feed function

Max. 240m/min (1mm) f f

Rapid traverse rate

Max. 100m/min (0.1mm) f f

Rapid traverse override Fo, 25, 50, 100% f f

Feed per minute f f

Feed per revolution f f

Tangential speed constant control f f

Cutting feedrate clamp f f

Automatic acceleration/ deceleration

Rapid traverse: linear

Cutting feed: exponential

f f

Rapid traverse bell–shaped

acceleration/deceleration

f f

Linear acceleration/ deceleration after cutting

feed interpolation

f f

Feedrate override 0–254% f f

One–digit F code feed f —

Jog override 0–655.34% f f

Override cancel f f

Manual per revolution feed — f

External deceleration f f

Advanced preview control Look ahead of multi–blocks f —

Program input

Tape code EIA RS244/ISO840 f f

Label skip f f

Parity check Horizontal and vertical parity f f

Control in/out f f

Optional block skip 9 f f

Max. programmable dimension "8–digit f f

Program number O4–digit f f

Sequence number N5–digit f f

Absolute/incremental programming Combined use in the same block f f
