23. AUTOMATIC OPERATION

B–63502EN/01

NC FUNCTION

198

Program number currently in need can be searched from the programs

registered in memory operating the MDI.

The sequence number of the program on the currently selected memory

can be searched using the MDI unit.

When executing the program from half-way (not from the head) of the

program, specify the sequence number of the half-way program, and the

program can be executed from the half-way block by sequence number

search.

After program execution has ended, the program in the memory or the

tape reader can be reminded to the program head, with this reset & rewind

signal on. (When a portable tape reader with reels is in use)

By specifying work numbers of 1 - 9999 externally (from the machine

side, etc.), program corresponding to the work number can be selected.

The work number equals the program number. For example when work

number 12 is specified, program, O0012 is selected.

23.2

SELECTION OF

EXECUTION

PROGRAMS

23.2.1

Program Number

23.2.2

Sequence Number

23.2.3

Rewind

23.2.4

External Workpiece

Number Search
