2. LIST OF SPECIFICATIONS

GENERAL

LIST OF SPECIFICATIONS

f : Standard F : Standard option

: Option

: : Function included in another option

NOTE

Some combinations of these options are

restricted.

Series 0i

Item Specifications

MA TA

Control axis

Controlled path 1 path f f

2 axes — f

Controlled axes per path

4 axes (Including Cs axis) f l

Simultaneously controlled axes Max. 4 axes f f

Axis control by PMC

Max. simultaneous 4 axes (Not available

on Cs axis)

f f

Cs contouring control 1 axis f f

Basic three axes are X, Y and Z, additional

axes are optional from U, V, W, A, B and C.

f —

Axis name

In case of G code system A, basic 2 axes

are X and Z, additional axes are optional

from Y, A, B and C.

— f

In case of G code system B/C, basic 2

axes are X and Z, additional axes are

optional from Y, U, V, W, A, B and C.

— f

Simple synchronous control 1 pair f f

Least input increment 0.001mm, 0.001deg, 0.0001inch f f

Increment system 1/10

0.0001mm, 0.0001deg,

0.00001inch

f f

Flexible feed gear Optional DMR f f

Fine Acc & Dec control f f

HRV control f f

Inch/metric conversion f f

Interlock

All axes/each axis/each direction/block

start/cutting block start

f f

Machine lock All axes/each axis f f

Emergency stop f f

Overtravel f f

Stored stroke check 1 f f

Stroke limit external setting f —

Stored stroke check 2 f —

Stored stroke check 2, 3 — f

Mirror image Each axis f f

Machine controlled

axes
