B–61863E–1/06

3. DATA CONTROL FUNCTION

PMC CONTROL SOFTWARE

Various data is accessed by a corresponding funciton.

Function Function name

DI from MT

DI from NC

pl_memc,pl_mems,pl_meml

pl_membrd

pl_memc2,pl_mems2,pl_meml2

pl_membrd2

DO to MT

DO to NC

pl_memc,pl_mems,pl_meml

pl_membwt

pl_memc2,pl_mems2,pl_meml2

pl_membwt2

Control relay, nonvolatile memory, etc. pl_memc,pl_mems,pl_meml

pl_membrd,pl_membwt

pl_memc2,pl_mems2,pl_meml2

pl_membrd2,pl_membwt2

NC data pl_nc_windr,pl_nc_windw

MDI keyboard pl_mdikey,pl_keydef

pl_keysts,pl_fkey_ign

pl_fkey_avil,pl_fkey_sts

CRT character display pl_dspclr,pl_dspclrl

pl_dspclrc,pl_dsppos

pl_dspcolor,pl_dspattr

pl_dspstr,pl_dspstrw

pl_dsptrblr,pl_cursor

pl_dspopen,pl_dspopen2

pl-dspopen3,pl_dspchar

pl_dspsave,pl_dspresave

pl_dspcntl

CRT graphic display pl_grpopen,pl_grpclose

pl_grpclr,pl_grpdspon

pl_grplntyp,pl_grpcolor

pl_grpline,pl_grparc

pl_paint,pl_grpopen2

pl_grpsft,pl_grpstatus

I/O with the reader/punch interface pl_rsopen,pl_rsclose

pl_rsrd,pl_rswrt

pl_fopen,pl_fdir,pl_fdel

Expanded nonvolatile memory pl_kpmrd,pl_kpmwrt,kpmsiz

NC command program pl_nc_dwnstart,pl_nc_download

pl_nc_dwnend,pl_nc_vrfstart

pl_nc_verify,pl_nc_vrfend

pl_nc_dncstart,pl_nc_dnc

pl_nc_dncend,pl_nc_search

pl_nc_delall,pl_nc_delete

pl_nc_upstart,pl_nc_upload

pl_nc_upend,pl_nc_dir

pl_nc_pdirstart,pl_progdir

pl_nc_pdirend

3.1.2

Access Method

3.1.3

Functions
