14. MMC WINDOW LIBRARYPMC LIBRARY

361

SC/SC3/SC4 NB/NB2 16i/18i/21i 15i–A

f f f 

[Name]

pl_mmcww

[Description]

Writes data of up to 32 bytes via the window between PMC and

MMC-II or MMC-III.

The contents of data can be determined arbitrarily by the PMC,

MMC-II, or MMC-III application program.

[Format]

ret = pl_mmcww(write_len,write_buffer);

short ret ;

unsigned short write_len ;

char *write_buffer ;

[Input]

write_len Specifies the data size (up to 32 bytes) to be sent to

MMC-II or MMC-III.

Data

[Output]

______

[Returns]

ret Complete code : –11, –10, –1, 0, 2, or 6

–11: Initialization of the MMC-II or MMC-III is not completed.

–10: Data is being written.

–1: The request was ignored because this function is being used by

function instruction MMCWW or another task.

0: Normal termination

2: The specified data length is incorrect. (Data length = 0, minus,

or 33 or more)

6: There is no required option. (MMC-II or MMC-III is not

provided.)

[Remarks]

______

14.2

WRITING WINDOW

DATA INTO MMC

write_buffer

Data to be sent to MMC-II or MMC-III is set.
