B–61863E–1/06
13. NC COMMAND PROGRAM
(PMC-NB/NB2/15i–A)
PMC LIBRARY
327
Completion
code
Description Related functions
–11 The processing to start or terminate the function is not
executed.
pl_nc_download, pl_nc_dwnend,
pl_nc_verify, pl_nc_vrend, pl_nc_dnc,
pl_nc_dncend, pl_nc_upload, pl_nc_upend,
pl_nc_progdir, pl_nc_pdirend
–10 A function is being processed. pl_nc_download, pl_nc_dwnend,
pl_nc_verify, pl_nc_vrend, pl_nc_dnc,
pl_nc_dncend, pl_nc_upload, pl_nc_upend,
pl_nc_progdir, pl_nc_pdirend, pl_nc_search,
pl_nc_delete, pl_nc_delall
–2 The CNC is reset. pl_nc_download, pl_nc_dwnend,
pl_nc_verify, pl_nc_vrend, pl_nc_dnc,
pl_nc_dncend, pl_nc_upload, pl_nc_upend,
pl_nc_progdir, pl_nc_pdirend
–4 Call the close processing. pl_nc_download, pl_nc_verify, pl_nc_dnc,
pl_nc_upload, pl_nc_progdir
–1 Reject (The CNC cannot execute the specified processing
because it is in the background edit mode or is busy.)
pl_nc_dwnstart, pl_nc_vrfstart,
pl_nc_dncstart, pl_nc_search, pl_nc_delall,
pl_nc_delete, pl_nc_upstart, pl_nc_dir,
pl_nc_progdir
0 Normal termination All functions
8 Either of the following occurs:
The program to be registered does not begin with its
program number. Alternatively, the program is
memory-protected and cannot be registered.
pl_nc_dwnend
22 An attempt was made to enter a value that is out of the
allowable range.
pl_nc_dwnend, pl_nc_drcend
30 The specified program number is not registered. pl_nc_upend, pl_nc_vrend, pl_nc_search,
pl_nc_delete
42 The specified program number has already been
registered.
pl_nc_dwnend
44 The tape area is full. pl_nc_dwnend
50 Too many programs are registered. pl_nc_dwnend
56 The program to be registered does not begin with its
program number.
pl_nc_dwnend
60 An attempt was made to erase a running program. pl_nc_delall, pl_nc_delete
NC program format
Parameter 0 of the CNC contains bits for specifying the tape format.
0000 EIA NCR ISP
Eight-bit data is:
0: Written in even parity.
1: Not written in even parity.
The tape format uses:
0: The ISO code.
1: The EIA code.
EOB is marked with:
0: LF CR CR (%OA %OD %OD).
1: LF (%OA).
