PMC-MODEL SC/SC3/SC4/NB/NB2 (C Language Programming) Programming manual Page 185

Programming manual

Page of 619

/ 619

B–61863E–1/06

2. PMC SYSTEM CALLPMC LIBRARY

169

SC/SC3/SC4 NB/NB2 16i/18i/21i 15i–A

f f f f

[Name]

os_make_pkt

[Description]

Selects the packet from the packet or memory pool.

[Format]

ret = os_make_pkt(packet_type,packet_address) ;

unsigned short ret ;

unsigned char packet_type ;

unsigned char **packet_address ;

[Input]

packet_type Packet type (0 to 3)

[Output]

*packet_address Packet address

[Returns]

ret Completion code

0 ; The packet has been selected normally.

011BH ; There is no packet block to be selected in the packet or

memory pool.

011FH ; Packet type error (other than 0 to 3)

0120H ; There is no empty packet.

0143H ; There is no memory pool.

015FH ; Incorrect segment selector

0160H ; Incorrect segment type

0162H ; No empty segment

[Remarks]

The packet types that can be specified by packet_type are listed

below. If the packet pool is insufficient, the packet is automatically

selected from the memory pool.

paket_type Size (bytes) Quantity

128

256

2.27

SELECTING THE

PACKET
