PMC-MODEL SC/SC3/SC4/NB/NB2 (C Language Programming) Programming manual Page 497

Programming manual

Page of 619

/ 619

B–61863E–1/06

C. DIFFERENCES BETWEEN THE PMC-SC

AND THE PMC-N, AND HOW TO

MIGRATE FROM THE PMC-N/NA TO

THE PMC-SC/SC3/SC4/NB/NB2

APPENDIX

481

Locked state

Run state

Ready state

Wait state Stopped state

os_chng_pri

(plock)

os_puls_flg OR os_sign_flg

(pwakeup)

-----

(pstart)

-----

(pstop)

os_wait_flg

(pwait)

os_chng_pri

(punlock)

(The functions in parentheses are used for the PMC-N/NA.)

(1) The PMC-SC/SC3/SC4 or PMC-NB/NB2 does not have a command

for stopping tasks on the PMC-SC/SC3/SC4 or PMC-NB.

(2) To move a task on the PMC-SC/SC3/SC4 or PMC-NB to the stopped

state as with the PMC-N/NA, create programs in such a manner that

the PMC-SC/SC3/SC4 or PMC-NB is placed in the wait state

(os_wait_flg) and tasks of the PMC-SC/SC3/SC4 or PMC-NB are

performed from the beginning when another task sends the signal

(os_puls_flg or os_sign_flg) to do so.

(3) When the entry function of a task relinquishes control, the task is

placed in the stopped state permanently.

C.1

STATE TRANSITION

OF TASKS

Contents Summary of PMC-MODEL SC/SC3/SC4/NB/NB2 (C Language Programming) Programming manual

Page 1GE Fanuc Automation Europe Computer Numerical Controls PMC - C Language Programming Manual B-61863E-1/06 TECHNOLOGY AND MORE
Page 2
Page 3B–61863E–1/06 DEFINITION OF WARNING, CAUTION, AND NOTE DEFINITION OF WARNING, CAUTION, AND NOTE This manual includes safety precautions for protecting the user and preventing damage to the machine. Precautions are classified into Warning and Caution according to their bearing on safety. Also, supple
Page 4B–61863E–1/06 PREFACE PREFACE The models covered by this manual, and their abbreviations are: Product Name Abbreviation Applicable CNC FANUC PMC–MODEL SC PMC–SC FANUC Series 16 MODEL A FANUC PMC–MODEL SC3 PMC–SC3 FANUC Series 16 MODEL A/B/C FANUC Series 18 MODEL B/C FANUC PMC–MODEL SC4 PMC–SC4 FANUC
Page 5B–61863E–1/06 Table of Contents DEFINITION OF WARNING, CAUTION, AND NOTE . . . . . . . . . . . . . . . . . . . . . . . . . . s–1 PREFACE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p–1 I. GENERAL 1. GENERAL . . . . .
Page 6Table of Contents B–61863E–1/06 2.4 REGISTRATION OF TASKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57 2.4.1 Addresses and the Number of User GDTs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 7B–61863E–1/06 Table of Contents III. PMC LIBRARY 1. GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135 2. PMC SYSTEM CALL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 8Table of Contents B–61863E–1/06 4. MDI KEYS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180 4.1 READING THE MDI KEYS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 9B–61863E–1/06 Table of Contents 8.9 DISPLAYING CHARACTERS TRIPLED IN SIZE ON THE CRT SCREEN . . . . . . . . . . . . . . . . . 220 8.10 DISPLAYING THE CURSOR ON THE CRT SCREEN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221 8.11 INITIALIZING THE CRT CHARACTER DISPLAY (PMC STAN
Page 10Table of Contents B–61863E–1/06 10.9 CLOSING THE READER/PUNCHER INTERFACE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 269 10.10 INPUTTING DATA THROUGH THE READER/PUNCHER INTERFACE . . . . . . . . . . . . . . . . . . 270 10.11 OUTPUTTING DATA THROUGH THE READER/PUNCHER INT
Page 11B–61863E–1/06 Table of Contents 12.21 OUTPUTTING (DOWNLOADING) NC COMMAND DATA TO BE REGISTERED . . . . . . . . . . 306 12.22 TERMINATING THE OUTPUT (DOWNLOAD) OF NC COMMAND DATA TO BE REGISTERED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 12Table of Contents B–61863E–1/06 13.17 EXECUTING PROCESSING TO START INPUTTING THE LIST OF PROGRAM NUMBERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 350 13.18 INPUTTING THE LIST OF PROGRAM NUMBERS . . . . . . . . . . . . . .
Page 13B–61863E–1/06 Table of Contents IV. APPLICATION PROGRAMMING GUIDE 1. DEVELOPMENT PROCEDURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 389 2. DETERMINING THE SPECIFICATIONS OF THE C PROGRAMS . . . . . . . . . . . . 390 2.1 DIVIDING INTO TASKS . . . . . . . . .
Page 14Table of Contents B–61863E–1/06 9.3 DEBUG FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 430 9.3.1 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 15B–61863E–1/06 Table of Contents D.2 MEMORY MANAGEMENT FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 492 D.3 SEMAPHOR MANAGEMENT FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 493 D.4 EVENT GRAPH MANAGEME
Page 16Table of Contents B–61863E–1/06 J. REFERENCE DOCUMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 554 J.1 LIBRARY OF CONGRES CATALOGINIGN IN PUBLICATION DATA THE C PROGRAMMING LANGUAGE. SECOND EDITION . . . . . . . . . . . . . . . . . . . . . . . . . .
