PMC-MODEL SC/SC3/SC4/NB/NB2 (C Language Programming) Programming manual Page 345

Programming manual

Page of 619

/ 619

B–61863E–1/06

13. NC COMMAND PROGRAM

(PMC-NB/NB2/15i–A)

PMC LIBRARY

329

SC/SC3/SC4 NB/NB2 16i/18i/21i 15i–A

 f  f

The PMC sends program data to the NC and the program is registered in

the NC. The program number is added when pl_nc_download is issued.

Processing flowchart

Is the termination requested or is the

function terminated abnormally?

pl_nc_dwnstart

pl_nc_download

pl_nc_dwnend

Catalogs a program.

Yes

If pl_nc_dwnstart returns a completion code of –1, call pl_nc_dwnend

without calling pl_nc_download.

[Name]

pl_nc_dwnstart

[Description]

Start registering (downloading) the data of the NC program.

[Format]

ret = pl_nc_dwnstart();

short ret ;

[Input]

______

[Output]

______

[Returns]

ret Complete code: –1 or 0

–1 : The request for starting output of the data of the NC command

to be registered was rejected. The completion code is returned

if the command is specified while the NC is in a background

edit mode or upload mode specified by another NC command.

0 : The NC has normally terminated preparation to start

downloading.

13.1

EXECUTING

PROCESSING TO

REGISTERING

(DOWNLOADING)

THE DATA OF THE

NC COMMAND TO BE

REGISTERED
