PMC-MODEL SC/SC3/SC4/NB/NB2 (C Language Programming) Programming manual Page 245

Programming manual

Page of 619

/ 619

B–61863E–1/06

8. CRT CHARACTER DISPLAYPMC LIBRARY

229

SC/SC3/SC4 NB/NB2 16i/18i/21i 15i–A

f  f 

[Name]

pl_dspsave

[Description]

Saves the specified part of the screen being displayed, the entire

character display data, and attributes.

However, the cursor cannot be saved.

[Format]

ret = pl_dspsave(P1,P2,P3);

short ret ;

short P1 ;

short *P2 ;

unsigned char *P3 ;

[Input]

P1 Specifies screen saving.

By specifying numbers 1 to 5, a part of the character data and

attributes being displayed on the CRT screen can be saved.

Five screen parts can be saved and up to 80 characters can be

saved for each part.

P1 Specifies screen saving.

0 Specifies that the display characters for one screen are to be saved.

1 to 5 Specifies that part of the screen (up to 80 characters) is to be saved.

(Five screen parts)

*P2 The start and end points for saving part of the screen, and the

number of columns to be saved (up to 80 characters) (NOTE1)

Start column

Start row

Number of columns to be saved (C)

*P3 Screen saving work area pointer (NOTE2)

[Output]

______

[Returns]

ret Completion code: –1, 0, 3, or 5

[Remarks]

NOTE

1 Up to 80 characters appears between the start and end

locations. P2 need not be set when one screen is saved.

2 The saving work buffer requires 11290 bytes. It is used for

screen restoration (pl_dspresave). However, 1690 bytes

are required only when part of the screen is saved.

8.15

SAVING THE CRT

CHARACTER

DISPLAY

X coordinate

Y coordinate

C=1 to 80
